ConnectionProvider::AbstractConnectionWithInfo Class Referenceabstract

abstract base class for connections More...

Inheritance diagram for ConnectionProvider::AbstractConnectionWithInfo:

Public Member Methods

 constructor (string name, string description, string url, hash< auto > attributes={}, hash< auto > options={})
 creates the AbstractConnection object More...

hash< ConnectionSchemeInfogetConnectionSchemeInfo ()
 Returns the ConnectionSchemeInfo hash for this object.

*hash< auto > getDefaultOptions ()
 returns default options

*hash< auto > getOptions ()
 returns static / initialization options

- Public Member Methods inherited from ConnectionProvider::AbstractConnection
deprecated constructor (string n_name, string n_desc, string n_url, bool n_monitor, *hash n_opts, hash n_urlh, *string n_safe_url, *bool n_enabled)
 creates the AbstractConnection object More...

 constructor (string name, string description, string url, hash< auto > attributes={}, hash< auto > options={})
 creates the AbstractConnection object More...

object get (bool connect=True, *hash< auto > rtopts)
 returns the underlying connection object More...

hash< ConfigInfogetConfigHash ()
 returns a ConfigInfo hash of static configuration information about the connection More...

hash< ConnectionSchemeInfogetConnectionSchemeInfo ()
 Returns a default ConnectionSchemeInfo hash.

AbstractDataProvider getDataProvider ()
 returns a data provider object for this connection, if supported More...

*hash< auto > getDefaultOptions ()
 returns default options

hash< ConnectionInfogetInfo (bool with_password=False)
 returns a ConnectionInfo hash of information about the connection More...

*hash< auto > getOptions ()
 returns static / initialization options

*hash< auto > getRealOptions ()
 returns options for saving the connection's configuration information

*hash< auto > getRuntimeOptions ()
 returns runtime options

auto getTag (string tag)
 returns the value of the given tag or NOTHING if not present

auto getTagEx (string tag)
 returns the value of the given tag or throws an exception if the tag is not set with a value More...

hash< auto > getTags ()
 returns all tags associated with the connection

abstract string getType ()
 returns the string type name for the connection object

bool hasDataProvider ()
 returns True if the connection returns a data provider with the getDataProvider() method More...

 parseTextOptions ()
 this method is called when parsing connection file definitions from text files when loading into the database More...

hash< PingInfoping (bool throw_exception=False)
 returns a hash with the results of the ping operation More...


Private Member Methods

abstract hash< ConnectionSchemeInfogetConnectionSchemeInfoImpl ()
 Returns the ConnectionSchemeInfo hash for this object.

- Private Member Methods inherited from ConnectionProvider::AbstractConnection
abstract object getImpl (bool connect=True, *hash< auto > rtopts)
 this method must return the connection object corresponding to the object's configuration More...

string getSafeUrl (hash< auto > urlh)
 creates a "safe" URL string with password information removed More...

hash< UrlInfo > parseUrl (string url)
 Parse the URL to a hash. More...

hash< PingInfopingIntern (hash< PingInfo > rv)
 performs the ping by executing get(); returns a PingInfo hash

hash< auto > validateOptions (hash< auto > options)
 performs options validation in the constructor More...


Additional Inherited Members

- Public Attributes inherited from ConnectionProvider::AbstractConnection
bool debug_data = False
 debug data flag; to be used an an indication for a higher-level implementation

string desc
 connection description

bool enabled = True
 enabled/disabled indicator flag

hash< auto > internal_info
 internal tags

date last_check
 date/time of last check/ping

bool locked = False
 locked/unlocked flag

bool loopback = False
 set to True for loopback connections

bool monitor
 monitoring flag

string name
 connection name

*hash< auto > opts
 connection options

*hash< auto > orig_opts
 original connection options

string safe_url
 "safe" URL (password information removed)

string status = "not checked"
 status string; in case of a connection error this string will be the error string

hash< auto > tags = {}
 connection tags; user-defined key-value pairs

bool up = False
 connection status flag; set by monitoring or explicit pings/connections

date updated
 date/time of last update

string url
 connection URL (potentially with password info)

hash< auto > urlh
 broken down URL hash (as returned by Qore::parse_url())

- Static Public Attributes inherited from ConnectionProvider::AbstractConnection
static *code post_processing
 optional code for default post-processing of objects created by getImpl(); must take the connection object and the object created as arguments


Detailed Description

abstract base class for connections

this class can be specialized to provide for user-defined connection types

Member Function Documentation

◆ constructor()

ConnectionProvider::AbstractConnectionWithInfo::constructor ( string  name,
string  description,
string  url,
hash< auto >  attributes = {},
hash< auto >  options = {}
)

creates the AbstractConnection object

Parameters
namethe name of the connection
descriptionconnection description
urlconnection URL (potentially with password info)
attributesvarious attributes; see below
optionsconnection options
Attributes
Attributes are special flags for given connection - stored as public attributes of the object instance. For now there are:
  • enabled (bool), default True
  • monitor (bool), default True
  • locked (bool), default False
  • tags (hash), no default value
Exceptions
CONNECTION-OPTION-ERRORmissing or invalid connection option
