items schema object for non-body parameters More...

Inheritance diagram for Swagger::ParameterItemsSchemaObject:

[legend]

Static Public Member Methods
static ParameterItemsSchemaObject	newSchemaObject (string name, auto error, SwaggerSchema swagger)
	throws an `"INVALID-FIELD-TYPE"` exception More...

static ParameterItemsSchemaObject	newSchemaObject (string name, hash< auto > oh, SwaggerSchema swagger)
	returns a SchemaObject for the schema definition; resolves references More...

Static Public Member Methods inherited from Swagger::SchemaObject
static SchemaObject	newSchemaObject (string name, auto error, SwaggerSchema swagger)
	throws an `"INVALID-FIELD-TYPE"` exception More...

static SchemaObject	newSchemaObject (string name, hash< auto > oh, SwaggerSchema swagger)
	returns a SchemaObject for the schema definition; resolves references More...

Static Public Member Methods inherited from Swagger::SchemaBase
static bool	checkValueType (reference< auto > value, string type)
	Checks the value against the type. More...

Public Attributes
*string	collectionFormat
	Determines the format of the array if type array is used. More...

Public Attributes inherited from Swagger::SchemaObject
auto	additionalProperties
	See https://tools.ietf.org/html/draft-fge-json-schema-validation-00#section-5.4.4. More...

auto	defaultVal
	See https://tools.ietf.org/html/draft-fge-json-schema-validation-00#section-6.2.

*string	desc
	See https://tools.ietf.org/html/draft-fge-json-schema-validation-00#section-6.1.

*string	discriminator
	Adds support for polymorphism. More...

auto	example
	A free-form property to include an example of an instance for this schema.

*ExternalDocumentationObject	externalDocs
	Additional external documentation for this schema.

*string	format
	The extending format for the previously mentioned `type`. See Data Type Formats for further details.

*SchemaObject	items
	See https://tools.ietf.org/html/draft-fge-json-schema-validation-00#section-5.3.1.

*int	maxProperties
	See https://tools.ietf.org/html/draft-fge-json-schema-validation-00#section-5.4.1.

*int	minProperties
	See https://tools.ietf.org/html/draft-fge-json-schema-validation-00#section-5.4.2.

string	name
	the name of this object for documentation and example purposes

bool	nullable = False
	extension that allows types to be nullable More...

hash< string, SchemaObject >	properties
	See https://tools.ietf.org/html/draft-fge-json-schema-validation-00#section-5.4.4. More...

bool	readOnly = False
	Relevant only for Schema `"properties"` definitions. Declares the property as "read only". More...

const	ReferenceTypes = ...
	valid reference types

hash< string, bool >	required
	See https://tools.ietf.org/html/draft-fge-json-schema-validation-00#section-5.4.3. More...

const	ScalarTypes = ...
	valid scalar types

*string	title
	See https://tools.ietf.org/html/draft-fge-json-schema-validation-00#section-6.1.

string	type
	See https://tools.ietf.org/html/draft-fge-json-schema-validation-00#section-5.5.2. More...

*XmlObject	xml
	This MAY be used only on properties schemas. It has no effect on root schemas. More...

Public Attributes inherited from Swagger::ObjectBase
hash< auto >	vendorExtensions
	Allows extensions to the Swagger Schema. More...

Public Attributes inherited from Swagger::SchemaBase
hash< string, bool >	enum
	See https://tools.ietf.org/html/draft-fge-json-schema-validation-00#section-5.5.1. More...

*bool	exclusiveMax
	See https://tools.ietf.org/html/draft-fge-json-schema-validation-00#section-5.1.2.

*bool	exclusiveMin
	See https://tools.ietf.org/html/draft-fge-json-schema-validation-00#section-5.1.3.

*float	maximum
	See https://tools.ietf.org/html/draft-fge-json-schema-validation-00#section-5.1.2.

*int	maxItems
	See https://tools.ietf.org/html/draft-fge-json-schema-validation-00#section-5.3.2.

*int	maxLength
	See https://tools.ietf.org/html/draft-fge-json-schema-validation-00#section-5.2.1.

*float	minimum
	See https://tools.ietf.org/html/draft-fge-json-schema-validation-00#section-5.1.3.

*int	minItems
	See https://tools.ietf.org/html/draft-fge-json-schema-validation-00#section-5.3.3.

*int	minLength
	See https://tools.ietf.org/html/draft-fge-json-schema-validation-00#section-5.2.2.

*float	multipleOf
	See https://tools.ietf.org/html/draft-fge-json-schema-validation-00#section-5.1.1.

*string	pattern
	See https://tools.ietf.org/html/draft-fge-json-schema-validation-00#section-5.2.3.

*bool	uniqueItems
	See https://tools.ietf.org/html/draft-fge-json-schema-validation-00#section-5.3.4.

Private Member Methods
	constructor (string name, hash< auto > oh, SwaggerSchema swagger)
	private constructor; use newSchemaObject() instead More...

Private Member Methods inherited from Swagger::SchemaObject
	check (bool serialize, bool request, string path, string method, string name, reference< auto > value)
	validates the value against the schema definition

Private Member Methods inherited from Swagger::SchemaBase
	checkIntern (bool serialize, bool request, string type, *string format, string path, string method, string name, date v, reference value)
	converts strings to/from date/time values for supported formats

auto	getExampleValue (string type, *string format)
	returns an example value for the given type

Additional Inherited Members
Public Member Methods inherited from Swagger::SchemaObject
list< SchemaObject >	allOf ()
	See https://tools.ietf.org/html/draft-fge-json-schema-validation-00#section-5.5.3. More...

private	checkIntern (bool serialize, bool request, string type, *string format, string path, string method, string name, hash< auto > v, reference< hash< auto >> value)
	validates a schema object against a value

Public Member Methods inherited from Swagger::ObjectBase
	constructor ()
	Constructor.

	constructor (hash< auto > oh)
	Constructor. More...

	constructor (ObjectBase other)
	copy constructor

	initialize (hash< auto > oh)
	Initialize. More...

Public Member Methods inherited from Swagger::SchemaBase
private	check (bool serialize, bool request, string type, string format, SchemaObject items, string path, string method, string name, reference< auto > value)
	validates the value against the schema definition

private	checkArrayParam (bool serialize, bool request, SchemaObject items, string path, string method, string name, reference< softlist< auto >> value)
	validates the value against the schema definition

private	checkIntern (bool serialize, bool request, string type, *string format, string path, string method, string name, binary v, reference value)
	converts binary values to strings for supported formats

private	checkIntern (bool serialize, bool request, string type, *string format, string path, string method, string name, string v, reference< auto > value)
	validates string values

	constructor (SchemaBase other)
	Copy constructor.

	constructor (string objType, hash< auto > oh)
	Constructor. More...

Static Private Member Methods inherited from Swagger::SchemaObject
static	checkValueType (reference< auto > value, string type, SchemaObject items, string loc)
	validates default values

Static Private Member Methods inherited from Swagger::SchemaBase
static	throwInvalidType (string name, string actual, string expected, auto value)
	throws an `SCHEMA-VALIDATION-ERROR` exception

Detailed Description

items schema object for non-body parameters

Member Function Documentation

◆ constructor()

Swagger::ParameterItemsSchemaObject::constructor	(	string	name,
		hash< auto >	oh,
		SwaggerSchema	swagger
	)

private

private constructor; use newSchemaObject() instead

Parameters

name	the name of the object
oh	deserialized hash from the source schema description describing an object in the schema
swagger	the REST schema for resolving references

Exceptions

INVALID-FIELD-FORMAT	field has invalid format
INVALID-FIELD-TYPE	field has invalid type
INVALID-FIELD-VALUE	field has invalid value
INVALID-COLLECTION-FORMAT	invalid collectionFormat value
INVALID-REFERENCE	cannot resolve reference; unknown attributes in description
REQUIRED-FIELD-MISSING	required field is missing

◆ newSchemaObject() [1/2]

static ParameterItemsSchemaObject Swagger::ParameterItemsSchemaObject::newSchemaObject	(	string	name,
		auto	error,
		SwaggerSchema	swagger
	)

static

throws an "INVALID-FIELD-TYPE" exception

Exceptions

INVALID-FIELD-TYPE due to a type error in the call

◆ newSchemaObject() [2/2]

static ParameterItemsSchemaObject Swagger::ParameterItemsSchemaObject::newSchemaObject	(	string	name,
		hash< auto >	oh,
		SwaggerSchema	swagger
	)

static

returns a SchemaObject for the schema definition; resolves references

Parameters

name	the name of the object
oh	deserialized hash from the source schema description describing an object in the schema
swagger	the REST schema for resolving references

Exceptions

INVALID-FIELD-FORMAT	field has invalid format
INVALID-FIELD-TYPE	field has invalid type
INVALID-FIELD-VALUE	field has invalid value
INVALID-COLLECTION-FORMAT	invalid collectionFormat value
INVALID-REFERENCE	cannot resolve reference; unknown attributes in description
REQUIRED-FIELD-MISSING	required field is missing

Member Data Documentation

◆ collectionFormat

*string Swagger::ParameterItemsSchemaObject::collectionFormat

Determines the format of the array if type array is used.

Possible values are:

"csv": comma separated values; ex: foo,bar
"ssv": space separated values; ex: foo bar
"tsv": tab separated values; ex: foo\tbar
"pipes": pipe separated values; ex: foo|bar
"multi": corresponds to multiple parameter instances instead of multiple values for a single instance foo=bar&foo=baz. This is valid only for parameters in "query" or "formData".

Default value is "csv".
