Qore Swagger Module Reference  2.0.9
Swagger::ParameterItemsSchemaObject Class Reference

items schema object for non-body parameters More...

Inheritance diagram for Swagger::ParameterItemsSchemaObject:

Static Public Member Methods

static ParameterItemsSchemaObject newSchemaObject (string name, auto error, SwaggerSchema swagger)
 throws an "INVALID-FIELD-TYPE" exception More...

static ParameterItemsSchemaObject newSchemaObject (string name, hash< auto > oh, SwaggerSchema swagger)
 returns a SchemaObject for the schema definition; resolves references More...

- Static Public Member Methods inherited from Swagger::SchemaObject
static SchemaObject newSchemaObject (string name, auto error, SwaggerSchema swagger)
 throws an "INVALID-FIELD-TYPE" exception More...

static SchemaObject newSchemaObject (string name, hash< auto > oh, SwaggerSchema swagger)
 returns a SchemaObject for the schema definition; resolves references More...

- Static Public Member Methods inherited from Swagger::SchemaBase
static bool checkValueType (reference< auto > value, string type)
 Checks the value against the type. More...


Public Attributes

*string collectionFormat
 Determines the format of the array if type array is used. More...

- Public Attributes inherited from Swagger::SchemaObject
auto additionalProperties
 See https://tools.ietf.org/html/draft-fge-json-schema-validation-00#section-5.4.4. More...

auto defaultVal
 See https://tools.ietf.org/html/draft-fge-json-schema-validation-00#section-6.2.

*string desc
 See https://tools.ietf.org/html/draft-fge-json-schema-validation-00#section-6.1.

*string discriminator
 Adds support for polymorphism. More...

auto example
 A free-form property to include an example of an instance for this schema.

*ExternalDocumentationObject externalDocs
 Additional external documentation for this schema.

*string format
 The extending format for the previously mentioned type. See Data Type Formats for further details.

*SchemaObject items
 See https://tools.ietf.org/html/draft-fge-json-schema-validation-00#section-5.3.1.

*int maxProperties
 See https://tools.ietf.org/html/draft-fge-json-schema-validation-00#section-5.4.1.

*int minProperties
 See https://tools.ietf.org/html/draft-fge-json-schema-validation-00#section-5.4.2.

string name
 the name of this object for documentation and example purposes

bool nullable = False
 extension that allows types to be nullable More...

hash< string, SchemaObjectproperties
 See https://tools.ietf.org/html/draft-fge-json-schema-validation-00#section-5.4.4. More...

bool readOnly = False
 Relevant only for Schema "properties" definitions. Declares the property as "read only". More...

const ReferenceTypes = ...
 valid reference types

hash< string, bool > required
 See https://tools.ietf.org/html/draft-fge-json-schema-validation-00#section-5.4.3. More...

const ScalarTypes = ...
 valid scalar types

*string title
 See https://tools.ietf.org/html/draft-fge-json-schema-validation-00#section-6.1.

string type
 See https://tools.ietf.org/html/draft-fge-json-schema-validation-00#section-5.5.2. More...

*XmlObject xml
 This MAY be used only on properties schemas. It has no effect on root schemas. More...

- Public Attributes inherited from Swagger::ObjectBase
hash< auto > vendorExtensions
 Allows extensions to the Swagger Schema. More...

- Public Attributes inherited from Swagger::SchemaBase
hash< string, bool > enum
 See https://tools.ietf.org/html/draft-fge-json-schema-validation-00#section-5.5.1. More...

*bool exclusiveMax
 See https://tools.ietf.org/html/draft-fge-json-schema-validation-00#section-5.1.2.

*bool exclusiveMin
 See https://tools.ietf.org/html/draft-fge-json-schema-validation-00#section-5.1.3.

*float maximum
 See https://tools.ietf.org/html/draft-fge-json-schema-validation-00#section-5.1.2.

*int maxItems
 See https://tools.ietf.org/html/draft-fge-json-schema-validation-00#section-5.3.2.

*int maxLength
 See https://tools.ietf.org/html/draft-fge-json-schema-validation-00#section-5.2.1.

*float minimum
 See https://tools.ietf.org/html/draft-fge-json-schema-validation-00#section-5.1.3.

*int minItems
 See https://tools.ietf.org/html/draft-fge-json-schema-validation-00#section-5.3.3.

*int minLength
 See https://tools.ietf.org/html/draft-fge-json-schema-validation-00#section-5.2.2.

*float multipleOf
 See https://tools.ietf.org/html/draft-fge-json-schema-validation-00#section-5.1.1.

*string pattern
 See https://tools.ietf.org/html/draft-fge-json-schema-validation-00#section-5.2.3.

*bool uniqueItems
 See https://tools.ietf.org/html/draft-fge-json-schema-validation-00#section-5.3.4.


Private Member Methods

 constructor (string name, hash< auto > oh, SwaggerSchema swagger)
 private constructor; use newSchemaObject() instead More...

- Private Member Methods inherited from Swagger::SchemaObject
 check (bool serialize, bool request, string path, string method, string name, reference< auto > value)
 validates the value against the schema definition

- Private Member Methods inherited from Swagger::SchemaBase
 checkIntern (bool serialize, bool request, string type, *string format, string path, string method, string name, date v, reference value)
 converts strings to/from date/time values for supported formats

auto getExampleValue (string type, *string format)
 returns an example value for the given type


Additional Inherited Members

- Public Member Methods inherited from Swagger::SchemaObject
list< SchemaObjectallOf ()
 See https://tools.ietf.org/html/draft-fge-json-schema-validation-00#section-5.5.3. More...

private checkIntern (bool serialize, bool request, string type, *string format, string path, string method, string name, hash< auto > v, reference< hash< auto >> value)
 validates a schema object against a value

- Public Member Methods inherited from Swagger::ObjectBase
 constructor ()
 Constructor.

 constructor (hash< auto > oh)
 Constructor. More...

 constructor (ObjectBase other)
 copy constructor

 initialize (hash< auto > oh)
 Initialize. More...

- Public Member Methods inherited from Swagger::SchemaBase
private check (bool serialize, bool request, string type, *string format, *SchemaObject items, string path, string method, string name, reference< auto > value)
 validates the value against the schema definition

private checkArrayParam (bool serialize, bool request, SchemaObject items, string path, string method, string name, reference< softlist< auto >> value)
 validates the value against the schema definition

private checkIntern (bool serialize, bool request, string type, *string format, string path, string method, string name, binary v, reference value)
 converts binary values to strings for supported formats

private checkIntern (bool serialize, bool request, string type, *string format, string path, string method, string name, string v, reference< auto > value)
 validates string values

 constructor (SchemaBase other)
 Copy constructor.

 constructor (string objType, hash< auto > oh)
 Constructor. More...

- Static Private Member Methods inherited from Swagger::SchemaObject
static checkValueType (reference< auto > value, string type, *SchemaObject items, *string loc)
 validates default values

- Static Private Member Methods inherited from Swagger::SchemaBase
static throwInvalidType (string name, string actual, string expected, auto value)
 throws an SCHEMA-VALIDATION-ERROR exception


Detailed Description

items schema object for non-body parameters

Member Function Documentation

◆ constructor()

Swagger::ParameterItemsSchemaObject::constructor ( string  name,
hash< auto >  oh,
SwaggerSchema  swagger
)
private

private constructor; use newSchemaObject() instead

Parameters
namethe name of the object
ohdeserialized hash from the source schema description describing an object in the schema
swaggerthe REST schema for resolving references
Exceptions
INVALID-FIELD-FORMATfield has invalid format
INVALID-FIELD-TYPEfield has invalid type
INVALID-FIELD-VALUEfield has invalid value
INVALID-COLLECTION-FORMATinvalid collectionFormat value
INVALID-REFERENCEcannot resolve reference; unknown attributes in description
REQUIRED-FIELD-MISSINGrequired field is missing

◆ newSchemaObject() [1/2]

static ParameterItemsSchemaObject Swagger::ParameterItemsSchemaObject::newSchemaObject ( string  name,
auto  error,
SwaggerSchema  swagger
)
static

throws an "INVALID-FIELD-TYPE" exception

Exceptions
INVALID-FIELD-TYPEdue to a type error in the call

◆ newSchemaObject() [2/2]

static ParameterItemsSchemaObject Swagger::ParameterItemsSchemaObject::newSchemaObject ( string  name,
hash< auto >  oh,
SwaggerSchema  swagger
)
static

returns a SchemaObject for the schema definition; resolves references

Parameters
namethe name of the object
ohdeserialized hash from the source schema description describing an object in the schema
swaggerthe REST schema for resolving references
Exceptions
INVALID-FIELD-FORMATfield has invalid format
INVALID-FIELD-TYPEfield has invalid type
INVALID-FIELD-VALUEfield has invalid value
INVALID-COLLECTION-FORMATinvalid collectionFormat value
INVALID-REFERENCEcannot resolve reference; unknown attributes in description
REQUIRED-FIELD-MISSINGrequired field is missing

Member Data Documentation

◆ collectionFormat

*string Swagger::ParameterItemsSchemaObject::collectionFormat

Determines the format of the array if type array is used.

Possible values are:

  • "csv": comma separated values; ex: foo,bar
  • "ssv": space separated values; ex: foo bar
  • "tsv": tab separated values; ex: foo\tbar
  • "pipes": pipe separated values; ex: foo|bar
  • "multi": corresponds to multiple parameter instances instead of multiple values for a single instance foo=bar&foo=baz. This is valid only for parameters in "query" or "formData".

Default value is "csv".
