Logger::LoggerAppenderWithLayout Class Reference

Implements an appender with a layout. More...

Inheritance diagram for Logger::LoggerAppenderWithLayout:

Public Member Methods
	constructor (*string name, LoggerLayout layout)
	Creates the object. More...
LoggerLayout	getLayout ()
	Returns the layout for the appender.
	setLayout (LoggerLayout layout)
	Assigns a layout to the appender. More...
Public Member Methods inherited from Logger::LoggerAppender
	addFilter (LoggerFilter filter, bool top=False)
	Adds a filter to the chain. More...
	close ()
	Releases any resources allocated by the appender and closes it.
	constructor (*string name)
	Creates the object. More...
list< LoggerFilter >	getFilters ()
	Returns the filter chain as a list. More...
string	getName ()
	Returns the appender name.
*LoggerAppenderQueue	getQueue ()
	Returns async queue or NOTHING when events are processed synchronously.
bool	isOpen ()
	Returns True if the appender is open and therefore active.
	open ()
	Opens logging resources. More...
bool	post (LoggerEvent event)
	Posts the given event to the output queue. More...
abstract	processEventImpl (int type, auto params)
	Processes the event to the physical target. More...
	removeAllFilters ()
	Clears the filter chain by removing all filters.
	removeFilter (LoggerFilter filter)
	Removes the given filter from the filter chain. More...
	setQueue (*LoggerAppenderQueue queue)
	Sets the appender queue. More...

Private Member Methods
auto	serializeImpl (LoggerEvent event)
	Returns the value formatted using the layout pattern. More...
Private Member Methods inherited from Logger::LoggerAppender
bool	pushEvent (int type, auto params)
	Pushes the given event on the queue or calls processEventImpl() in case of synchronous processing. More...

Private:Internal Attributes
LoggerLayout	layout
	assigned layout

Additional Inherited Members
Public Attributes inherited from Logger::LoggerAppender
const	EVENT_CLOSE = 3
	close event
const	EVENT_LOG = 2
	logging event
const	EVENT_OPEN = 1
	open event

Detailed Description

Implements an appender with a layout.

The layout is responsible for formatting the LoggerEvent according to the user's wishes, whereas an appender takes care of sending the formatted output to its destination.

It is used typically for appenders implementing logging to a file

Member Function Documentation

constructor()

Logger::LoggerAppenderWithLayout::constructor	(	*string	name,
		LoggerLayout	layout
	)

Creates the object.

Parameters

name	the name of the appender
layout	the layout for the appender

serializeImpl()

auto Logger::LoggerAppenderWithLayout::serializeImpl ( LoggerEvent  event )

privatevirtual

Returns the value formatted using the layout pattern.

Parameters

event

the event to serialize

Implements Logger::LoggerAppender.

setLayout()

Logger::LoggerAppenderWithLayout::setLayout

(

LoggerLayout

layout

)

Assigns a layout to the appender.

Parameters

layout

the layout for the appender
