Logger::LoggerAppenderFileArchive Class Reference

Implements appender writing to a file with archive support. More...

Inheritance diagram for Logger::LoggerAppenderFileArchive:

Public Member Methods
string	archive ()
	Posts an archive event. More...
	constructor (*string name, LoggerLayout layout, string filename, string archive=DEFAULT_ARCHIVE_PATTERN, *string encoding)
	Creates the object. More...
string	getArchiveFileName ()
	Returns the archive filename. More...
	processEventImpl (int type, auto params)
	Implements archiving, handles the archive event directly, passes all other events to the subclass for handling. More...
Public Member Methods inherited from Logger::LoggerAppenderFile
	constructor (*string name, LoggerLayout layout, string filename, *string encoding)
	Creates the object. More...
File	getFile ()
	Returns the file object for the appender.
string	getFileName ()
	Returns the current filename.
Public Member Methods inherited from Logger::LoggerAppenderWithLayout
	constructor (*string name, LoggerLayout layout)
	Creates the object. More...
LoggerLayout	getLayout ()
	Returns the layout for the appender.
	setLayout (LoggerLayout layout)
	Assigns a layout to the appender. More...
Public Member Methods inherited from Logger::LoggerAppender
	addFilter (LoggerFilter filter, bool top=False)
	Adds a filter to the chain. More...
	close ()
	Releases any resources allocated by the appender and closes it.
	constructor (*string name)
	Creates the object. More...
list< LoggerFilter >	getFilters ()
	Returns the filter chain as a list. More...
string	getName ()
	Returns the appender name.
*LoggerAppenderQueue	getQueue ()
	Returns async queue or NOTHING when events are processed synchronously.
bool	isOpen ()
	Returns True if the appender is open and therefore active.
	open ()
	Opens logging resources. More...
bool	post (LoggerEvent event)
	Posts the given event to the output queue. More...
	removeAllFilters ()
	Clears the filter chain by removing all filters.
	removeFilter (LoggerFilter filter)
	Removes the given filter from the filter chain. More...
	setQueue (*LoggerAppenderQueue queue)
	Sets the appender queue. More...

Public Attributes
const	DEFAULT_ARCHIVE_PATTERN = "%p%f.%d"
	default archive pattern
const	DEFAULT_DATE_FORMAT = "YYYYMMDDHHmmSS"
	default date format
const	EVENT_ARCHIVE = 20
	archive event
Public Attributes inherited from Logger::LoggerAppenderFile
const	EVENT_REOPEN = 1001
	reopen event
Public Attributes inherited from Logger::LoggerAppender
const	EVENT_CLOSE = 3
	close event
const	EVENT_LOG = 2
	logging event
const	EVENT_OPEN = 1
	open event

Private Member Methods
*string	resolveField (auto data, string key, *string option)
	Returns a string for a format field for a pattern-based filename or archive file name. More...
Private Member Methods inherited from Logger::LoggerAppenderWithLayout
auto	serializeImpl (LoggerEvent event)
	Returns the value formatted using the layout pattern. More...
Private Member Methods inherited from Logger::LoggerAppender
bool	pushEvent (int type, auto params)
	Pushes the given event on the queue or calls processEventImpl() in case of synchronous processing. More...
	constructor (string pattern)
	Creates the object. More...
string	format (auto data)
	Formats the event record with the current pattern. More...
string	getPattern ()
	Returns the current pattern.
	setPattern (string value)
	Sets the new pattern. More...

Additional Inherited Members
Private Attributes inherited from Logger::LoggerPattern
list< auto >	parsedPattern
	parsed pattern; list elements may be strings or hashes
const	ESCAPE_CHAR = "%"
	format escape character

Detailed Description

Implements appender writing to a file with archive support.

The events will be logged to a file until archiving is triggered. At that moment the current file is closed, moved to file with name evaluated in runtime from the archive pattern set in the object, the new file is created, and logging continues to that file. The archive never overwrites any existing file.

Member Function Documentation

archive()

string Logger::LoggerAppenderFileArchive::archive

(

)

Posts an archive event.

rename logging file and open new one

Returns

archive file name

Exceptions

LOGGER-ERROR

if target file name is not correct or target file already exists

constructor()

Logger::LoggerAppenderFileArchive::constructor	(	*string	name,
		LoggerLayout	layout,
		string	filename,
		string	archive = DEFAULT_ARCHIVE_PATTERN,
		*string	encoding
	)

Creates the object.

Parameters

name	the name of the appender
layout	the layout for the appender
filename	with pattern support; see below for more information
archive	pattern to evaluate archive filename; see below for more information
encoding	the output file's encoding

The following table explains the characters used in LoggerPattern for both filename and archive parameter

Conversion character	Meaning
%s	Used to output the OS directory separator, i.e. "\" or "/"
%c	Used to output the appender name
%C	Used to output the appender class name
%E	Used to output the environment variable with name given by option, e.g. "%E{HOME}"
%%	The literal percent sign. "%%" will print a "%" sign

The following table explains the characters used in LoggerPattern for archive parameter only

Conversion character	Meaning
%P	Used to output the current logging path with filename
%p	Used to output the current logging path
%f	Used to output the current logging filename
%d	Used to output the date of the logging event using format_date. Option may specify date </td>

format, e.g. "%d{DD.MM.YYYY HH:mm:SS}", default value is "YYYYMMDDHHmmSS" |

For example, the archive pattern "%p/archive/%d/%f" archives log file "/var/run/log/MyLogger.log" to: "/var/run/log/archive/20180120102030/MyLogger.log".

getArchiveFileName()

string Logger::LoggerAppenderFileArchive::getArchiveFileName

(

)

Returns the archive filename.

The pattern may contain date fields so the result may differ when executed multiple times

processEventImpl()

Logger::LoggerAppenderFileArchive::processEventImpl ( int  type, auto  params  )

virtual

Implements archiving, handles the archive event directly, passes all other events to the subclass for handling.

Parameters

type	the event code
params	event parameters

Reimplemented from Logger::LoggerAppenderFile.

resolveField()

*string Logger::LoggerAppenderFileArchive::resolveField ( auto  data, string  key, *string  option  )

privatevirtual

Returns a string for a format field for a pattern-based filename or archive file name.

Parameters

data	if NOTHING, then this argument specifies the logging filename, otherwise is specifies the archive pattern
key	the format character
option	the format option value, if any

Returns

the formatted string

Implements Logger::LoggerPattern.
